    C9500-16X-E Enterprise Managed Switch C9500 16 Port 10Gig

    Ask Lasest Price
    Brand Name : N/A
    Model Number : C9500-16X-E Enterprise Managed Switch
    Certification : N/A
    Price : $7700---8000 Negotiable
    Payment Terms : Western Union T/T Bank Wire
    Supply Ability : 25 PCS 130 DAYS
    Delivery Time : 2---3 Working days
    • Product Details
    • Company Profile

    C9500-16X-E Enterprise Managed Switch C9500 16 Port 10Gig

    C9500-16X-E Enterprise Managed Switch C9500 16-port 10Gig switch Essentials


    Products Overview

    C9500-16X-E Overview C9500-16X-E Enterprise Managed Switch
    C9500-16X-E is a C9500 16-port 10G switch, NW Ess. License. The C9500 Series Switches are the next
    generation of enterprise-class core and aggregation layer switches, supporting full programmability and serviceability. Based on
    an x86 CPU, the Catalyst 9500 Series is lead purpose-built fixed core and aggregation enterprise switching platform, built
    for security, IoT, and cloud. The Catalyst 9500 Series is the industry's first purpose-built 40 Gigabit Ethernet line of switches
    targeted for the enterprise campus. C9500-16X-E Enterprise Managed Switch C9500 16-port 10Gig switch Essentials.


    Specification

    C9500-16X-E Enterprise Managed Switch C9500 16-port 10Gig switch Essentials

    Switching capacityUp to 240 Gbps
    Forwarding rateUp to 360 Mpps
    Total number of MAC addressesUp to 64,000
    Total number of IPv4 routes (Address Resolution Protocol [ARP] plus learned routes)

    Up to 64,000 indirect

    Up to 80,000 host

    C9500-16X-E Enterprise Managed Switch

    Total number of IPv6 routes

    Up to 32,000 indirect

    Up to 40,000 host

    QoS ACL scaleUp to 18000
    Security ACL scaleUp to 18000
    FNF entriesUp to 512,000
    DRAM16 GB C9500-16X-E Enterprise Managed Switch
    Flash16 GB
    VLAN IDs4000
    Total Switched Virtual Interfaces (SVIs)4000
    Jumbo frame9198 bytes
    Power supply specifications
    Power Supply SelectionPWR-C4-950WAC-R or PWR-C4-950WDC-R
    Power max rating950W C9500-16X-E Enterprise Managed Switch
    Dimensions, physical specifications, weight, and MTBF
    Dimensions (H x W x D)1.73 x 17.5 x 21.52 in
    Rack units (RU)1RU C9500-16X-E Enterprise Managed Switch
    Chassis with 2 power supplies and built-In fan23.6 lb (10.7 kg)
    Input voltage90 to 264 VAC
    Operating temperature32° to 104°F (0° to 40°C)
    Storage temperature-4° to 149°F (-20° to 65°C)
    Relative humidity operating and nonoperating noncondensing

    Ambient (noncondensing) operating: 5% to 90%

    Ambient (noncondensing) nonoperating and storage: 5% to 95%

    AltitudeOperation up to 6000 feet at 55°C and 13,000 feet at 45°C
    MTBF (hours)315,790
