C9400-LC-48U Network Firewall Device 9400 Series 48 Port UPOE 10/100/1000 RJ-45

HIZON INFORMATION TECHNOLOGY LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap C9400-LC-48U Network Firewall Device 9400 Series 48 Port UPOE 10/100/1000 RJ-45 from wholesalers

    Buy cheap C9400-LC-48U Network Firewall Device 9400 Series 48 Port UPOE 10/100/1000 RJ-45 from wholesalers
    • Buy cheap C9400-LC-48U Network Firewall Device 9400 Series 48 Port UPOE 10/100/1000 RJ-45 from wholesalers

    C9400-LC-48U Network Firewall Device 9400 Series 48 Port UPOE 10/100/1000 RJ-45

    Ask Lasest Price
    Brand Name : N/A
    Model Number : C9400-LC-48U Network Firewall Device
    Certification : N/A
    Price : $1400 Negotiable
    Payment Terms : Western Union T/T Bank Wire
    Supply Ability : 10 pcs in 3 days
    Delivery Time : 2---3 Working days
    • Product Details
    • Company Profile

    C9400-LC-48U Network Firewall Device 9400 Series 48 Port UPOE 10/100/1000 RJ-45

    C9400-LC-48U Network Firewall Device 9400 Series 48-Port UPOE 10/100/1000 (RJ-45)


    Products Overview

    9400 Series 48-Port UPOE 10/100/1000 (RJ-45) C9400-LC-48U Features 48 ports nonblocking 10/100/1000 module (RJ-45) Supported on Open IOS-XE release 16.6.1 or later UPoE is enabled, capable of up to 60W on all the ports in the line card Energy Efficient Ethernet 802.3az IEEE 802.3af/at and pre-standard PoE IEEE 802.1AE and TrustSec capability in hardware (Software Roadmap) Hardware-ready for IEEE1588/802.1AS and PTP used for time synchronization across the network for applications such as video and audio. (Software Roadmap) Layer 2 to Layer 4 Jumbo Frame support up to 9216 bytes Enterprise and commercial design to power next-generation IP phones, wireless base stations, video cameras, virtual desktop clients, and other PoE/UPoE devices C9400-LC-48U Network Firewall Device Switch Cards
    Specification
    Model Number
    C9400-LC-48U Network Firewall Device Switch Cards
    Standards
    ● Gigabit Ethernet: IEEE 802.3z, IEEE 802.3x, IEEE 802.3ab, IEEE 803.3at, IEEE 802.3af, IEEE 802.3az C9400-LC-48U Network Firewall Device Switch card
    EtherChannel Technology
    ● Gigabit EtherChannel: All 1000 Mbps ports
    ● 10 Gigabit EtherChannel: All 10Gbps ports
    ● IEEE 802.3ad (Link Aggregation Control Protocol): All 1000 Mbps ports
    ● Port Aggregation Protocol (PagP): Yes
    ● Number of ports per tuple: 8
    ● EtherChannel and IEEE 802.3ad technology across line cards: Yes
    Physical Dimensions
    ● Occupies one slot in the Cisco Catalyst 9400 Series platform
    ● Dimensions (H x W x D): 1.6 x 14.92 x 14.57 in. (4.06 x 37.90 x 37.00 cm)
    C9400-LC-48U Network Firewall Device switch card
    Environmental Conditions
    ● Operating temperature:
    ● Normal Operating Temperature and Altitudes:
    ◦ 27° to 109°F (-5 to +45°C), up to 6,000 feet (1800 m)
    ◦ 27° to 104°F (-5 to +40°C), up to 10,000 feet (3000 m)
    ◦ *Minimum ambient temperature for cold startup is 0°C
    ● Short-Term Exceptional Conditions:
    ◦ 27° to 119°F (-5 to +55°C), up to 6,000 feet (1800 m)
    ◦ 27° to 114°F (-5 to +50°C), up to 10,000 feet (3000 m)
    ◦ Not more than following in one-year period: 96 consecutive hours, or 360 hours total, or 15 occurrences
    ● Storage temperature: -40° to 158° F (-40° to 70°C)
    ● Relative humidity: 10 to 95%, noncondensing
    ● Operating altitude: -60 to 3000m
    Safety Conditions
    Fiber optic lasers: Class 1 laser products
    Safety Certifications
    ● UL 60950-1
    ● CAN/CSA-C222.2 No. 60950-1
    ● EN 60950-1
    ● IEC 60950-1
    ● AS/NZS 60950.1
    ● IEEE 802.3 C9400-LC-48U Network Firewall Device switch card
    Electromagnetic Emissions Certifications
    ● 47 CFR Part 15
    ● CISPR22 Class A
    ● EN 300 386 V1.6.1
    ● EN 55022 Class A
    ● EN 55032 Class A
    ● CISPR 32 Class A
    ● EN61000-3-2
    ● EN61000-3-3
    ● ICES-003 Class A
    ● TCVN 7189 Class A
    ● V-3 Class A
    ● CISPR24
    ● EN 300 386
    ● EN55024
    ● TCVN 7317
    ROHS Compliance
    ROHS5
